Hyperscale Chicago Data Center Campus

Prime Data Centers is building a new hyperscale Chicago data center campus in a close suburb of the Windy City – Elk Grove Village. The campus will have up to three buildings totaling up to 175MW of critical capacity. It is currently available for pre-lease.

Up to 175MW of Critical Power

Prime Data Centers is developing a new Chicago data center in Elk Grove Village, Illinois. The facility will be a world-class site for hyperscale cloud operations. We encourage interested parties to contact us and take advantage of the opportunity to work with Prime Data Centers early on in the planning phases of this project so that the site can be built to your requirements and specifications.

Get the Brochure

Prime’s Chicago Data Center Property Details

Lot & Building

  • 17 acres
  • Dry pipe, dual-interlock pre-action sprinkler system
  • Building A:
  • 3-story, 384,000 square foot purpose-built data center
  • Data hall area: 200,000 sq. ft.
  • Fully entitled development
  • Secured loading dock
  • Building B
  • 3-story, 354,000 square foot purpose-built data center
  • Data hall area: 162,000 sq. ft.

Power & Reliability

  • Power: 275 MVA served from ComEd
  • Redundancy:
  • Tailored, redundant topologies
  • Block or distributed-redundant power blocks
  • Concurrently maintainable
  • On-site dedicated substation
  • 2N PDU distribution

Cooling & Efficiency

  • PUE: 1.25 (annualized at 100% capacity)
  • Redundancy:
  • N+1 chilled water system
  • N+2 distributed CRAH units
  • Concurrently maintainable
  • Cabinet density:
  • Capable of supporting density in excess of 20kW per cabinet depending on configuration​

Connectivity

  • Carrier-neutral facility
  • Dual-fiber entrances and Meet-Me Rooms
  • Dark fiber services available, connectivity to local hubs

Safety & Security

  • Perimeter fencing with vehicular gate badge access
  • Biometric and key-card access controls
  • 24 x 7 on-site security personnel
  • Internal/external building CCTV coverage

Chicago Data Center Benefits

There’s a good reason why Chicago is one of the most sought-after data center markets in the United States. Downtown Chicago and its surroundings, like Elk Grove Village, have a business-friendly environment, with specific benefits to data center development. As far as resilience and disaster recovery requirements, the area has a relatively low-risk profile for flooding, seismic activity, hurricanes, and other natural disasters. The local power supply is also relatively strong, including a new Elk Grove smart substation. This new substation was recently brought online and will be able to support 60MVA of additional load to the area. The cost of power is relatively inexpensive, rounding out an already impressive power profile.
Chicago data center hyperscale

Cloud Services in Chicago

As the cloud continues to transform the way businesses operate, Prime’s Chicago data center is perfect for major cloud providers and hyperscalers looking to expand and boost their presence in this thriving region.

Routinely on the top list of data center markets, Chi-town is a booming technology hub that will only continue to grow as digital transformation moves to the forefront. Home to many leading tech companies, Chicago data needs to be housed in close proximity to today’s savvy end users.

Prime’s hyperscale data center located in Chicago has made national headlines. To see our recent press, visit our press page here.

Request Information

We are your wholesale data center real estate development partner of choice. Whether you’re interested in data center consolidation strategy, site selection, equity or tax opportunities, or data center solution design, we want to hear from you.

You can fill out the form or text us at 415-896-4418.

Prime Data Centers offers purpose-built, turnkey data center real estate development, sale-leaseback and powered-shell options with unique customer partnership structures and potential tax advantages.
